HELIX 10 CHIRP MEGA SI + GPS G4N
HELIX 10 CHIRP MEGA SI + GPS G4N
PREORDER
Original price
€0
Original price
€1,795.00
-
Original price
€1,795.00
Original price
Current price
€1,795.00
€1,795.00
-
€1,795.00
Current price
€1,795.00
| /
The HELIX 10 CHIRP MEGA SI + GPS G4N boasts a 10.1" screen and advanced features such as MEGA Side Imaging+, MEGA Down Imaging+, and Dual Spectrum CHIRP Sonar. HELIX 10 CHIRP MEGA SI + GPS G4N also has an internal GPS with Humminbird Basemap and standard features like AutoChart Live and NMEA 2000®, as well as compatibility with the One-Boat Network™ from Humminbird, Minn Kota, and Cannon through Bluetooth® and Ethernet networking.
Effortlessly control your HELIX with the keypad and preloaded views, even in tough conditions. Utilize MEGA Side Imaging+ to see unprecedented detail and range up to 200 feet on both sides of your boat, gaining an edge in finding fish and structures.
Unlock more fish & structure w/ MEGA Down Imaging+! Get 20% more detail & 60% more depth capability than regular sonar. Dual Spectrum CHIRP sonar w/ highly-detailed fish arches & clear view of the structure. Powered by our own Low-Q CHIRP transducer, choose Wide or Narrow Mode for maximum or detailed coverage.
Enhance your fishing and navigation experience with our Internal GPS and Humminbird Basemap. Easily identify important underwater terrain features and points of interest, such as hazards, marinas, and depth markers. Choose from over 10,000 included lake charts and premium options from Humminbird's LakeMaster® and CoastMaster™ products, as well as compatible Navionics® charts for a complete view of the world below.
With AutoChart Live, map your fishing spots in real-time using Humminbird® LakeMaster® features. Includes 8 hours of recording and can be expanded with AutoChart Zero Line SD cards. Compatible with One-Boat Network for advanced features and control.
Ethernet Networking: Connect multiple fish finders and add-on technologies like Minn Kota i-Pilot Link and Humminbird CHIRP Radar. Bluetooth: Control Talon and Raptor anchors and Cannon Optimum downriggers wirelessly from your Humminbird, with software updates and smartphone notifications available through the FishSmart App.
NMEA 2000 Networking: Connect an accessory network for more information on boat performance, weather, and water conditions. Includes control head, screen cover, transducer, power cable, gimbal bracket, and mounting hardware. 2-Year Limited Warranty.
Model
HELIX 10 CHIRP MEGA SI+ GPS G4N
Product Code
411420-1
Series
HELIX
UPC
0082324055034
Display Size - Diagonal
10.1 in
Display Pixel Matrix
1024H x 600V
Transducer Included
XM 9 HW MSI T
Compatible With
Minn Kota US2 Sonar, Minn Kota Built-In MEGA DI, Minn Kota Talon/Raptor, Minn Kota i-Pilot Link, Minn Kota Built-In MEGA SI, MEGA Live, AIS, NMEA 2000, MEGA 360, Radar, AutoPilot, One-Boat Network
Features
Networking, Down Imaging, Built In GPS, Bluetooth, Side Imaging, Dual Spectrum CHIRP, Built In Mapping, MEGA Imaging+
Memory Card Slot
Dual SD
Sonar-Standard
Dual Spectrum CHIRP, MEGA Side Imaging+, MEGA Down Imaging+
Sonar-Coverage
20°, 42°, 60°, (2) 86° & (2) 55° @ -10dB
Sonar-Optional
50/83/200 kHz
CHIRP - Frequencies Supported
Narrow Mode (180-240 kHz), Wide Mode (140-200 kHz), Full Mode (150-220 kHz), Optional (28-250 kHz)
Sonar-Frequencies Supported
50/83/200/455/800 kHz, HW DSC CHIRP, and MEGA
Depth-Sonar
3,500 ft (optional 50 kHz), 1,200 ft (standard transducer)
CHIRP - Imaging Frequencies Supported
MEGA DI+ (1100-1200 kHz), 800 kHz SI+ (780-840 kHz), 455 kHz SI+ (405-505 kHz), 800 kHz DI+ (800-860 kHz), MEGA SI+ (1050-1175 kHz), 455 kHz DI+ (420-520 kHz)
Depth-Down Imaging
200 ft (MEGA), 400 ft (455 kHz), 125 ft (800 kHz)
Range-Side Imaging (Side-To-Side)
800 ft (455 kHz), 250 ft (800 kHz), 400 ft (MEGA)
Interface
Keypad Control
Power Draw
2.7 Amps
Power Input
10.8-20 VDC
Power Output Peak-to-Peak
8000 Watts
Power Output RMS
1000 Watts
Screen Snap Shot
Included
Sonar Recording
Included
Mount-Standard
Gimbal
Mount-Standard Size
13.44 in W x 7.5 in H x 4.2 in D
Mount-Optional
In-Dash Mounting Kit
Mount-Optional Size
13.44 in W x 7.12 in H x 1.32 in D
Transducer Mount Location
Transom
GPS Chartplotting
Included
GPS Receiver
Internal
GPS Trackplotting
Included
Waypoints, Routes, Tracks/Points
2,750, 47, 50/20,000
360 Imaging Compatibility
Yes
MEGA Live Compatibility
Yes
Humminbird Basemap
Included
LakeMaster Compatibility
Yes
CoastMaster Compatibility
Yes
Navionics Gold/HotMaps Compatibility
Yes
Navionics Platinum+ Compatibility
Yes
Platinum Compatibility
Yes
Minn Kota i-Pilot Link Compatibility
Yes
Minn Kota Talon Shallow Water Anchor Compatibility
Yes
Radar Compatibility
Yes
5-Port Ethernet Switch Compatibility
Yes
AIS Compatibility
Optional
Autopilot Compatibility
Yes
Heading Sensor GPS Compatibility
Yes
NMEA2000
Included
Target Separation
2.5 in
Upgradable Software
Yes
View Preset Keys
Yes
X-Press Menu System
Yes
Custom Digital Readout
Yes
Custom View Selections
Yes
Display Colors Grayscale
16-Bit
Display Type
Color TFT
Speed
Included
Temperature
Built In
Temperature Alarm
Yes
Temperature Graph
Yes
HDMI Compatible
No
Warranty
Two-Year Warranty
