APEX 13 MEGA SI + CHARTPLOTTER
APEX 13 MEGA SI+ CHARTPLOTTER boasts unparalleled sonar imaging and a high-definition touchscreen display. Its industry-leading MEGA Imaging+ and Dual Spectrum CHIRP sonar are complemented by a dedicated channel for accessory 2D...
SKU:
411470-1
- €4,895.00
- €4,895.00
- Unit price
- per
APEX 13 MEGA SI+ CHARTPLOTTER boasts unparalleled sonar imaging and a high-definition touchscreen display. Its industry-leading MEGA Imaging+ and Dual Spectrum CHIRP sonar are complemented by a dedicated channel for accessory 2D CHIRP transducers up to 2kW. APEX 13 MEGA SI+ CHARTPLOTTER has advanced network options such as NMEA 2000®, HDMI In/Out, WiFi, and Bluetooth® provide a fully customizable display of information. Take your fishing to new depths with Humminbird GPS charts, Minn Kota® boat control, and wireless Cannon® Optimum™ downrigger control through the One-Boat Network™ integration. Revolutionize your fishing experience with the APEX Series and its advanced features.
Full-HD Display with Cross Touch® interface: APEX offers a 1920x1080 display for amazing detail in sonar and chart images. Control it with a touchscreen or keypad. Customizable interface and menu for a personalized fishing experience.
Fast and powerful processor. Advanced Humminbird sonar with MEGA Imaging+ and Dual Spectrum CHIRP for fish finding.
2-in-1 Sonar and GPS: Dual sonar ports allow connection with Humminbird sonar options and quick installation of transducers. Enhanced base map for confident navigation and fishing. Identify points of interest and underwater terrain easily.
Get a complete view with compatible premium charts from Humminbird. You can use Humminbird's LakeMaster® and CoastMaster™ or Navionics® charts to map your fishing spots in real-time with AutoChart Live. Includes 8 hours of recording and is compatible with AutoChart Zero Line SD cards for unlimited mapping potential.
Maximize your fishing experience with the APEX 13 MEGA SI + CHARTPLOTTER. It seamlessly integrates and communicates with Minn Kota motors and Cannon Optimum downriggers for exclusive boat control and advanced fish-catching features. The APEX chart plotters have dual Ethernet ports that allow easy networking of multiple control heads and accessories like Minn Kota i-Pilot Link and Humminbird CHIRP Radar, without the need for an external network hub.
APEX 13 MEGA SI + CHARTPLOTTER: Multiple HDMI ports for connecting cameras, videos, and displays, plus Bluetooth control for Talon, Raptor, and Cannon Optimum devices. Smartphone notifications and FishSmart App updates are available wirelessly.
Add an accessory NMEA 2000 network for more information. Compatible with CZone® Contact 6 and Contact 6 Plus. Includes control head, screen cover, transducer, hardware, power cable, and bracket. 2-Year Limited Warranty. Sleek low-profile design with front-mount in-dash kit.
| Model | APEX 13 MEGA SI+ CHARTPLOTTER |
| Product Code | 411470-1 |
| Series | APEX |
| UPC | 0082324055324 |
| Display Size - Diagonal | 13.3 in |
| Display Pixel Matrix | 1920H x 1080V |
| Transducer Included | XM 14 HW MSI T |
| Compatible With | Minn Kota US2 Sonar, Minn Kota Built-In MEGA DI, Minn Kota Talon/Raptor, Minn Kota i-Pilot Link, Minn Kota Built-In MEGA SI, HDMI In/Out, MEGA Live, AIS, NMEA 2000, MEGA 360, Radar, AutoPilot, One-Boat Network |
| Features | Touch Screen, MEGA Live Imaging, Networking, Down Imaging, Built In GPS, Side Imaging, Dual Spectrum CHIRP, Built In Mapping, MEGA Imaging+, Wi-Fi |
| Memory Card Slot | Dual Micro SD |
| Sonar-Standard | Dual Spectrum CHIRP, MEGA Side Imaging+, MEGA Down Imaging+ |
| Sonar-Coverage | 20°, 42°, 60°, (2) 86° & (2) 55° @ -10dB |
| Sonar-Optional | 50/83/200 kHz, Airmar High, High Wide, Medium, Medium Wide, and Low |
| CHIRP - Frequencies Supported | Narrow Mode (180-240 kHz), Optional Deepwater (28-250 kHz), Wide Mode (140-200 kHz), Full Mode (150-220 kHz) |
| Sonar-Frequencies Supported | 50/83/200/455/800 kHz, HW DSC CHIRP, and MEGA |
| Depth-Sonar | 3,500 ft (optional Airmar CHIRP), 1,200 ft (standard transducer) |
| CHIRP - Imaging Frequencies Supported | MEGA DI+ (1100-1200 kHz), 800 kHz SI+ (780-840 kHz), 455 kHz SI+ (405-505 kHz), 800 kHz DI+ (800-860 kHz), MEGA SI+ (1050-1175 kHz), 455 kHz DI+ (420-520 kHz) |
| Depth-Down Imaging | 250 ft (MEGA), 400 ft (455 kHz), 125 ft (800 kHz) |
| Range-Side Imaging (Side-To-Side) | 800 ft (455 kHz), 500 ft (MEGA), 250 ft (800 kHz) |
| Interface | Touch Screen |
| Power Draw | 3.1 Amps |
| Power Input | 10.8-20 VDC |
| Power Output Peak-to-Peak | 8000 Watts |
| Power Output RMS | 1000 Watts |
| Screen Snap Shot | Included |
| Sonar Recording | Included |
| Mount-Standard | Gimbal |
| Mount-Standard Size | 15.6 in W x 9.88 in H x 4.88 in D |
| Mount-Optional | In-Dash Mounting Kit |
| Mount-Optional Size | 15.6 in W x 8.98 in H x 0.51 in D |
| Transducer Mount Location | Transom |
| GPS Chartplotting | Included |
| GPS Receiver | Internal |
| GPS Trackplotting | Included |
| Waypoints, Routes, Tracks/Points | 10,000, 50, 50/20,000 |
| 360 Imaging Compatibility | Yes |
| MEGA Live Compatibility | Yes |
| Humminbird Basemap | Included |
| LakeMaster Compatibility | Yes |
| CoastMaster Compatibility | Yes |
| Navionics Gold/HotMaps Compatibility | Yes |
| Navionics Platinum+ Compatibility | Yes |
| Platinum Compatibility | Yes |
| Minn Kota i-Pilot Link Compatibility | Yes |
| Minn Kota Talon Shallow Water Anchor Compatibility | Yes |
| Radar Compatibility | Yes |
| 5-Port Ethernet Switch Compatibility | Yes |
| AIS Compatibility | Optional |
| Autopilot Compatibility | Yes |
| Heading Sensor GPS Compatibility | Yes |
| NMEA2000 | Included |
| Target Separation | 2.5 in |
| Upgradable Software | Yes |
| View Preset Keys | Yes |
| X-Press Menu System | No |
| Custom Digital Readout | Yes |
| Custom View Selections | Yes |
| Display Colors Grayscale | 16-Bit |
| Display Type | Color TFT |
| Speed | Included |
| Temperature | Built In |
| Temperature Alarm | Yes |
| Temperature Graph | Yes |
| HDMI Compatible | Yes |
| Warranty | Two-Year Warranty |
